3M™ Electrically Conductive Double-Sided Tape 9701, 500 mm x 100 m, 50 um - 7100263944
3M™ Electrically Conductive Double-Sided Tape 9701, 500 mm x 100 m, 50 um - 7100263944
3M™ Electrically Conductive Double-Sided Tape 9701, 500 mm x 100 m, 50 um - 7100263944
Previous Next

3M Products & Supplies

3M™ Electrically Conductive Double-Sided Tape 9701, 500 mm x 100 m, 50 um - 7100263944

SKU: 7100263944
MPN: 7100263944
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00638060907559
3M ID: WX300948840
5 Digit UPC: 90755
$5,465.91 each
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Adhesive Transfer Tape 9701 is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape. This double-sided tape has a nickel/copper-coated conductive nonwoven carrier. Designed for EMI shielding and grounding applications, enabling devices to meet electromagnetic compatibility requirements.

Features

  • Good handling and workability
  • Thicker construction to conform to non-flat surfaces
  • XYZ-conductivity through the adhesive
  • Good EMI shielding in bond line gap
  • Excellent conformability and quick bonding
  • Improved electrical contact to small size areas

Specifications

Shelf Life9.0 Month
Country of OriginSouth Korea
Backing (Carrier) MaterialNon-woven
Overall Width (Metric)500.0
Total Tape Thickness without Liner (Imperial)2.0
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Imperial) UOMmil
Adhesion Strength (Imperial)1000.0
Overall Width (Imperial)19.685
Overall Width (Imperial) UOMin
Overall Width (Metric) UOMmm
Overall Length (Metric)100.0
Adhesive TypeAcrylic
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Overall Length (Imperial)109.361
Product ColorGray
Total Tape Thickness without Liner (Metric) UOMmm
Electrical ResistanceXY-axis 0.2 Ω, Z-axis 0.05-0.08 Ω
Total Tape Thickness without Liner (Metric)0.05
ApplicationGrounding; Passive Intermodulation (PIM) Management
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Overall Length (Metric) UOMm
Product UsageBond Line Gaps; Flexible Printed Circuits; Sensors
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Liner MaterialPET
