3M™ Electrically Conductive Double-Sided Tape 9701-50, 25 mm x 10 m - 7010506059

Sold As: 16-Pack
SKU: 7010506059
MPN: 7010506059
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 18806080063749
3M ID: WX300926796
5 Digit UPC: 6374
$1,607.77 ($100.49 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double Sided Tape 9701 is an XYZ electrically conductive pressure sensitive adhesive (PSA) tape with a thickness of 50 microns and 100 microns. 3M Tape Series 9701 consists of a conductive matrix carrier (Nickel/copper coated conductive fabric matrix) that is electrically conductive and is designed for PSA attachment to the desired grounding surfaces.

Features

  • Good EMI shielding in bond line gap
  • Thicker construction to conform to non-flat surfaces
  • Improved electrical contact to small size areas
  • Good handling and workability
  • XYZ-conductivity through the adhesive
  • Excellent conformability and quick bonding
Spec Sheet



Downloads

Specifications

Shelf Life9.0 Month
Country of OriginSouth Korea
Product UsageBond Line Gaps; Flexible Printed Circuits; Sensors
Adhesion Strength (Imperial)1000.0
Liner MaterialPET
Overall Length (Imperial)10.936
Overall Length (Metric)10.0
Total Tape Thickness without Liner (Metric)0.05
Overall Length (Imperial) UOMyd
Electrical ResistanceXY-axis 0.2 Ω, Z-axis 0.05-0.08 Ω
Overall Width (Imperial)0.984
Overall Width (Metric)25.0
ApplicationGrounding; Passive Intermodulation (PIM) Management
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Overall Width (Metric) UOMmm
Backing (Carrier) MaterialNon-woven
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive TypeAcrylic
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Total Tape Thickness without Liner (Imperial)2.0
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Length (Metric) UOMm
Product ColorGray
