3M Products & Supplies

3M™ Electrically Conductive Double-Sided Tape 9711S, 25 mm x 10 m, 100um - 7100160646

Sold As: 4-Pack
SKU: 7100160646
MPN: 7100160646
Stock Item: Stock items typically ship within 2-3 business days
UPC: 18806080063763
3M ID: WX300926853
5 Digit UPC: 6376
$401.77 ($100.44 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 9711S is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. This double-sided conductive tape has a nickel/copper-coated conductive woven fabric carrier. It has very high electrical conductivity, which provides low resistance for small contact areas and high frequencies. This double-sided tape offers high adhesion and maintains low resistance over time, which provides excellent reliability in demanding environmental conditions. It brings robust protection against EMI in a range of market segments, including general electronics, consumer electronics, automotive, medical equipment, communications infrastructure, and aerospace and defense electronics.

Features

  • Isotropic XYZ-axis conductivity through the adhesive
  • Good EMI shielding in bond line gap
  • Thicker construction conforms to non-flat surfaces
  • Good handling and workability
  • Improved electrical contact to small-size areas
  • Excellent conformability and quick bonding

Downloads

Specifications

Shelf Life12.0 Month
Country of OriginSouth Korea
Maximum Operating Temperature (Celsius)85.0 Degree Celsius
Electrical ResistanceXY-axis 0.2 Ω, Z-axis 0.05-0.1 Ω
Maximum Operating Temperature (Fahrenheit)185.0 Degree Fahrenheit
Overall Width (Imperial)0.984
Total Tape Thickness without Liner (Imperial)4.0
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Overall Length (Imperial)10.936
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Adhesive TypeAcrylic
Overall Width (Metric)25.0
Overall Length (Metric)10.0
Overall Length (Metric) UOMm
Overall Width (Metric) UOMmm
Adhesion Strength (Imperial)2000.0
Backing (Carrier) MaterialWoven Fabric
Total Tape Thickness without Liner (Metric) UOMmm
Product ColorGray
Overall Length (Imperial) UOMyd
Product UsageBond Line Gaps; Chassis; EMI Gaskets; Flexible Printed Circuits; Printed Circuit Boards; Sensors
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Liner MaterialPET
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.1
Total Tape Thickness without Liner (Imperial) UOMmil
