3M Products & Supplies

3M™ Electrically Conductive Double-Sided Tape 9711S, 1060 mm x 100 m, 200um, 1 Roll/Case - 7010352933

SKU: 7010352933
MPN: 7010352933
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051131121928
3M ID: WX300950168
5 Digit UPC: 12192
$8,485.98 each
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 9711S is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. This double-sided conductive tape has a nickel/copper-coated conductive woven fabric carrier. It has very high electrical conductivity, which provides low resistance for small contact areas and high frequencies. This double-sided tape offers high adhesion and maintains low resistance over time, which provides excellent reliability in demanding environmental conditions. It brings robust protection against EMI in a range of market segments, including general electronics, consumer electronics, automotive, medical equipment, communications infrastructure, and aerospace and defense electronics.

Features

  • Improved electrical contact to small-size areas
  • Thicker construction conforms to non-flat surfaces
  • Good EMI shielding in bond line gap
  • Isotropic XYZ-axis conductivity through the adhesive
  • Good handling and workability
  • Excellent conformability and quick bonding

Downloads

Specifications

Shelf Life12.0 Month
Country of OriginSouth Korea
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Metric)100.0
Adhesive TypeAcrylic
Overall Length (Imperial)109.361
Overall Length (Imperial) UOMyd
Overall Length (Metric) UOMm
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Adhesion Strength (Imperial)1500.0
Maximum Operating Temperature (Fahrenheit)185.0 Degree Fahrenheit
Maximum Operating Temperature (Celsius)85.0 Degree Celsius
Liner MaterialPET
Backing (Carrier) MaterialWoven Fabric
Total Tape Thickness without Liner (Metric)0.2
Electrical ResistanceXY-axis 0.2 Ω, Z-axis 0.05-0.1 Ω
Product ColorGray
Overall Width (Metric)1060.0
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Product UsageBond Line Gaps; Chassis; EMI Gaskets; Flexible Printed Circuits; Printed Circuit Boards; Sensors
Overall Width (Imperial)41.732
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial)8.0
