3M Products & Supplies

3M™ Electrically Conductive Double-Sided Tape 5113DFT-50, Grey, 25 mm x 10 m, 12 Rolls/Case - 7100313600

Sold As: 12-Pack
SKU: 7100313600
MPN: 7100313600
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00068060428219
3M ID: 80001605148
$366.42 ($30.54 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 5113DFT is an electrically conductive double-sided fabric tape (DFT) that provides high adhesion, low electrical resistance, long shelf life, resistance to high temperature and humidity and excellent grounding and shielding performance. It features a proprietary polyolefin XYZ-axis conductive pressure sensitive adhesive (CPSA) and a conductive matrix carrier (a nickel/copper/nickel-coated conductive woven carrier). This grounding tape provides excellent adhesion to a variety of substrates including metals and plastics and helps control signal interference through passive intermodulation (PIM) mitigation for higher signal integrity and performance. This double-sided fabric tape helps protect against EMI in a range of market segments, including general industrial electronics, aerospace and defense electronics, appliances, automotive electronics and IoT devices, communications infrastructure, and medical equipment.

Features

  • Excellent EMI shielding performance for a wide range of frequencies
  • Long-term performance at high temperatures (105 ˚C) for demanding applications
  • Excellent grounding with small contact areas for microelectronics
  • Four-year shelf life for reliable, consistent performance over time
  • Excellent EMI shielding in bond line gap
  • Isotropic XYZ-axis conductivity through the adhesive
Spec Sheet



Downloads

Specifications

Shelf Life48.0 Month
Country of OriginChina
Electrical ResistanceXY-axis 0.01 Ω, Z-axis 0.03 Ω
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive TypePolyolefin
Backing (Carrier) MaterialWoven Fabric
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Liner MaterialPET
Overall Width (Metric) UOMmm
Product UsageBond Line Gaps; Chassis; EMI Gaskets; EMI Shields; Flexible Printed Circuits; Printed Circuit Boards; Sensors
Overall Width (Imperial) UOMin
Overall Width (Metric)25.0
Overall Width (Imperial)0.984
Total Tape Thickness without Liner (Imperial)2.0
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Overall Length (Metric)10.0
Overall Length (Metric) UOMm
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Product ColorGray
Total Tape Thickness without Liner (Metric)0.05
Overall Length (Imperial)10.936
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Adhesion Strength (Imperial)1500.0
Overall Length (Imperial) UOMyd
