3M Products & Supplies

3M ™ Electrically Conductive Double-Sided Tape 9772-30, 500 mm x 30 m, 1 Roll/Case - 7100313615

SKU: 7100313615
MPN: 7100313615
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060428370
3M ID: 80001605296
$922.43 each
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 9772 Series is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It consists of a conductive copper foil matrix carrier, a conductive acrylic adhesive, and a polyester (PET) release liner on the top and bottom. This thin, reliable copper shielding tape has high XY-axis electrical resistance compared to other standard double-sided conductive tapes. It offers excellent conformability, good EMI shielding in the bond line gap and excellent electrical contact to small-size grounding areas. The conductive acrylic-based adhesive provides high adhesion, especially for a thin double-sided tape.

Features

  • Good EMI shielding in the bond line gap
  • Conformable and bonds quickly
  • Thin profile
  • Isotropic XYZ-axis conductivity through the adhesive
  • Improved electrical contact to small-size areas
  • Excellent XY-axis electrical resistance
Spec Sheet



Downloads

Specifications

Shelf Life12.0 Month
Country of OriginSouth Korea
Overall Width (Imperial) UOMin
Backing (Carrier) MaterialCopper Foil
Adhesion Strength (Imperial)1100.0
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Width (Imperial)19.685
Total Tape Thickness without Liner (Metric)0.03
Total Tape Thickness without Liner (Imperial)1.2
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Overall Length (Metric) UOMm
Overall Width (Metric) UOMmm
Product ColorGold
Overall Length (Metric)30.0
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Electrical ResistanceXY-axis 0.015 Ω
Product UsageChassis; EMI Gaskets; EMI Shields; Flexible Printed Circuits; Sensors
Overall Length (Imperial)32.808
Liner MaterialPET
Adhesive TypeAcrylic
Overall Width (Metric)500.0
Total Tape Thickness without Liner (Metric) UOMmm
