3M Products & Supplies

3M ™ Electrically Conductive Double-Sided Tape 9772-50, 100 mm x 10 m, 8 Rolls/Case - 7100313616

Sold As: 8-Pack
SKU: 7100313616
MPN: 7100313616
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060428387
3M ID: 80001605304
$770.13 ($96.27 / Count)
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Double-Sided Tape 9772 Series is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It consists of a conductive copper foil matrix carrier, a conductive acrylic adhesive, and a polyester (PET) release liner on the top and bottom. This thin, reliable copper shielding tape has high XY-axis electrical resistance compared to other standard double-sided conductive tapes. It offers excellent conformability, good EMI shielding in the bond line gap and excellent electrical contact to small-size grounding areas. The conductive acrylic-based adhesive provides high adhesion, especially for a thin double-sided tape.

Features

  • Excellent XY-axis electrical resistance
  • Good EMI shielding in the bond line gap
  • Conformable and bonds quickly
  • Improved electrical contact to small-size areas
  • Thin profile
  • Isotropic XYZ-axis conductivity through the adhesive

Downloads

Specifications

Shelf Life12.0 Month
Country of OriginSouth Korea
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Overall Width (Imperial)3.937
Adhesive TypeAcrylic
Overall Width (Metric)100.0
Backing (Carrier) MaterialCopper Foil
Product ColorGold
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Length (Imperial) UOMyd
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Imperial) UOMmil
ApplicationAttaching; Electrostatic Discharge (ESD); Grounding; Interconnecting; Passive Intermodulation (PIM) Management
Liner MaterialPET
Total Tape Thickness without Liner (Metric) UOMmm
Product UsageChassis; EMI Gaskets; EMI Shields; Flexible Printed Circuits; Sensors
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Overall Length (Metric) UOMm
Electrical ResistanceXY-axis 0.015 Ω
Total Tape Thickness without Liner (Imperial)2.0
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.05
Overall Length (Imperial)10.936
Adhesion Strength (Imperial)1000.0
Overall Length (Metric)10.0
