3M™ Female Disconnect, Fully Nylon Insulated Butted Seam 12-10 AWG, 94832, 73F-250-32-NL - 7010397413

Sold As: 10-Pack
SKU: 7010397413
MPN: 7010397413
For an accurate lead time please contact us
UPC: 00054007948322
3M ID: 80611253321
MPN: 94832
$146.84 ($14.68 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Allows for quick and easy disconnect of wires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating

Downloads

Specifications

Maximum Conductor Size (Imperial)10 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Country of OriginUnited States
Connection Width (Imperial)0.25
Connection Width (Metric) UOMmm
Connection Width (Metric)6.35
Minimum Conductor Size (Imperial)12 AWG
Minimum Conductor Size (Metric)4 mm²
Connection Width (Imperial) UOMin
Disconnect TypeFemale
Terminal TypeDisconnect
Maximum Conductor Size (Metric)6 mm²
