3M Products & Supplies

3M™ Female Disconnect, Nylon Insulated with Insulation Grip Bullet Style 22-18 AWG, 94839, 81F-180-NBL-A - 7010293657

Sold As: 10-Pack
SKU: 7010293657
MPN: 7010293657
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138980863
3M ID: 80611444318
MPN: 94839-A
$281.84 ($28.18 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Allows for quick and easy disconnect of wires
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
Spec Sheet



Downloads

Specifications

Maximum Conductor Size (Metric)1 mm²
Connection Width (Imperial)0.18
Terminal TypeDisconnect
Minimum Conductor Size (Imperial)22 AWG
Country of OriginTaiwan
Maximum Conductor Size (Imperial)18 AWG
Connection Width (Metric)4.572
Disconnect TypeFemale
Connection Width (Metric) UOMmm
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Connection Width (Imperial) UOMin
Minimum Conductor Size (Metric).34 mm²
