3M Products & Supplies

3M™ Female Disconnect, Nylon Insulated with Insulation Grip Bullet Style 22-18 AWG, 94838, 81F-156-NBL-A - 7100165170

Sold As: 10-Pack
SKU: 7100165170
MPN: 7100165170
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138980825
3M ID: 80611444276
MPN: 94838
$245.06 ($24.51 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Allows for quick and easy disconnect of wires

Specifications

Country of OriginTaiwan
Connection Width (Imperial)0.156
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Conductor Size (Imperial)22 AWG
Minimum Conductor Size (Metric).34 mm²
Connection Width (Metric)3.962
Terminal TypeDisconnect
Disconnect TypeFemale
Connection Width (Metric) UOMmm
Connection Width (Imperial) UOMin
Maximum Conductor Size (Imperial)18 AWG
Maximum Conductor Size (Metric)1 mm²
