3M Products & Supplies

3M™ Nylon Insulated with Insulation Grip Bullet Style Female Disconnect, 81F-156-NBL-A, Max. Temp. -40 to 221 °F (-40 to 105 °C) - 7100165168

Sold As: 1000-Pack
SKU: 7100165168
MPN: 7100165168
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138980771
3M ID: 80611444227
MPN: 81F-156-NBL-A
$221.02 ($0.22 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Allows for quick and easy disconnect of wires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating

Specifications

Minimum Conductor Size (Imperial)22 AWG
Connection Width (Metric)3.962
Disconnect TypeFemale
Maximum Conductor Size (Metric)1 mm²
Terminal TypeDisconnect
Connection Width (Imperial) UOMin
Connection Width (Metric) UOMmm
Country of OriginTaiwan
Connection Width (Imperial)0.156
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Imperial)18 AWG
Minimum Conductor Size (Metric).34 mm²
