3M Products & Supplies

3M™ Nylon Insulated with Insulation Grip Bullet Style Female Disconnect, 82F-180-NBL-A, Max. Temp. -40 to 221 °F (-40 to 105 °C) - 7100165185

Sold As: 1000-Pack
SKU: 7100165185
MPN: 7100165185
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138981266
3M ID: 80611444714
MPN: 82F-180-NBL-A
$221.02 ($0.22 / Count)
Hurry up! Current stock:

Product Description

3M™ Standard Female Disconnect Terminals have dents and rolled edges to offer great holding force while allowing for quick and easy disconnect. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its durable brass construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Allows for quick and easy disconnect of wires

Specifications

Connection Width (Imperial) UOMin
Connection Width (Metric)4.572
Disconnect TypeFemale
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Metric)1.5 mm²
Connection Width (Imperial)0.18
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Metric)2.5 mm²
Minimum Conductor Size (Imperial)16 AWG
Connection Width (Metric) UOMmm
Country of OriginTaiwan
Terminal TypeDisconnect
