3M™ Flexomount™ Plate Mounting Tape 411DL is a double linered, double coated tape designed for mounting photopolymer and rubber printing plates to flexographic printing cylinders or sleeves. The adhesive is specially formulated for clean removal from both the plate and the print cylinder or sleeve.
Features
Downloads
| Overall Length (Metric) | 32.91 m |
|---|---|
| Application Thickness (Metric) | 0.4 mm |
| Overall Thickness (Imperial) | 15 mil |
| Application Thickness (Imperial) | 15 mil |
| Adhesive Type | Rubber |
| Composite Sleeves | Yes |
| Total Tape Thickness without Liner (Imperial) | 15 mil |
| Backing Material | Solid Vinyl |
| Primary Liner | Polycoated Kraft Paper |
| Product Color | Gray |
| Product Form | Roll |
| Primary Liner Thickness (Metric) | 0.1 mm |
| Air Release | No |
| Urethane Sleeves | Yes |
| Overall Width (Imperial) | 54 in |
| Overall Length (Imperial) | 36 yd |
| Warranty Period | 1 Year from Date of Manufacture |
| Print Quality | Solid Printing |
| Application | Flexographic Plate Mounting |
| Print Quality (Series) | 400 Series |
| Overall Width (Metric) | 1371.6 mm |
| Secondary Liner | Polyethylene |
| Total Tape Thickness without Liner (Metric) | 0.38 mm |
| Secondary Liner Thickness (Metric) | 0.1 mm |
| Primary Liner Thickness (Imperial) | 4 mil |
| Secondary Liner Thickness (Imperial) | 4 mil |
| Color Family | Gray |
| Product Number | 411DL |
