3M Products & Supplies

3M™ General Purpose PTFE Glass Cloth Tape 5151, Light Brown, 19 1/2 in x 36 yd, 5.3 mil, 2 rolls per case - 7000028980

Sold As: 2-Pack
SKU: 7000028980
MPN: 7000028980
Lead Time: 47 working days.
UPC: 021200558061
3M ID: 70006322252
5 Digit UPC: 55806
$4,400.00 ($2200.00 / Count)
Hurry up! Current stock:

Product Description

Formed from a light brown woven glass cloth backing impregnated with PTFE (polytetrafluoroethylene), 3M™ General Purpose PTFE Glass Cloth Tape 5151 provides a slick surface on process machinery. This tape offers an extremely low coefficient of friction which, in combination with a pressure sensitive silicone adhesive, creates a non-stick surface that performs at elevated temperatures.

Features

  • Provides a non-stick, low friction surface on heat sealing and packaging equipment
  • Performs under a wide range of temperatures, including up to 500°F/260°C
  • Excellent chemical resistance enables tape to withstand challenging applications
  • Silicone adhesive offers high temperature performance and long aging
  • Very low moisture absorption allows the tape to perform in many humid environments
  • Glass cloth reinforced backing provides greater tensile strength and resistance to tears and punctures than typical PTFE film backed tapes

Downloads

Specifications

Shelf Life24 Month
Elongation at Break5 %
Tensile Strength (Imperial)1760 oz/in
Adhesive TypeSilicone
Tensile Strength (Metric)1925 N/100mm
Backing Thickness (Metric)0.08 mm
Product FormRoll
Backing Thickness (Imperial)3 mil
Total Tape Thickness without Liner (Imperial)5.3 mil
Overall Width (Imperial)19.5 in
Total Tape Thickness without Liner (Metric)0.13 mm
Maximum Operating Temperature (Celsius)260 Degree Celsius
Product Number5151
Backing (Carrier) Thickness (Imperial)3 mil
Back Side Adhesive Thickness (Metric)en-US: 0.08 mm
Overall Length (Imperial)36 yd
Backing (Carrier) MaterialGlass Cloth/PTFE
Maximum Operating Temperature (Fahrenheit)500 Degree Fahrenheit
Overall Length (Metric)32.91 m
Color FamilyBrown
Overall Width (Metric)495.3 mm
Product ColorLight Brown
Minimum Operating Temperature (Fahrenheit)-100 Degree Fahrenheit
Backing MaterialGlass cloth impregnated w/PTFE
Backing (Carrier) Thickness (Metric)0.08 mm
Overall Thickness (Imperial)5.3 mil
Product Key5151
