3M Products & Supplies

3M™ Greenback Printed Circuit Board Tape 851 Green, 1/4 in x 72 yds x 4.0 mil, 144/Case - 7000144698

Sold As: 144-Pack
SKU: 7000144698
MPN: 7000144698
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200317798
3M ID: 70006226420
5 Digit UPC: 31779
$1,812.87 ($12.59 / Count)
Hurry up! Current stock:

Product Description

3M™ Circuit Plating Tape 851 with polyester film and blended silicone and rubber adhesive used for PCB masking and other high temperature applications. Thick adhesive coating. Green, 4.0 mil thick.

Features

  • Polyethylene tape core instead of cardboard
  • Polyester backing reduces stretch and recovery of tape associated with uneven stop-off line
  • Thick adhesive coating reduces undercutting because adhesive blocks out solutions between fingers
  • Specially designed adhesive that generally performs better when no ovens are used to heat tape and boards
Spec Sheet



Downloads

Specifications

Country of OriginMexico
Overall Length (Metric) UOMm
Overall Width (Metric) UOMmm
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric)0.091
Overall Width (Metric)6.35
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) MaterialPolyester
Overall Width (Imperial)0.25
Adhesive TypeSilicone/Rubber
Overall Length (Imperial)72.0
Total Tape Thickness without Liner (Imperial)3.6
Product ColorGreen
Overall Width (Imperial) UOMin
Overall Length (Metric)65.837
Total Tape Thickness without Liner (Metric) UOMmm
