3M Products & Supplies

3M™ H/D Nylon Insulated with Insulation Grip Ring Tongue Terminal 123-14-NB, 1000/case - 7100163738

Sold As: 1000-Pack
SKU: 7100163738
MPN: 7100163738
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007289074
3M ID: 80611255821
MPN: BS-31-8-P
$367.90 ($0.37 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Standard-style ring tongue fits around the stud
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance

Downloads

Specifications

Terminal TypeRing
Minimum Conductor Size (Imperial)16 AWG
Minimum Stud Diameter (Imperial) UOMin
Minimum Conductor Size (Metric)1.31 mm²
Maximum Operating Temperature (Celsius)175.0
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Imperial)12 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Terminal StyleStandard
Insulation MaterialNylon with Insulation Grip
Minimum Stud Diameter (Metric) UOMmm
Barrel Length (Imperial)0.25 Inch
Country of OriginUnited States
Ring TypeStandard
Barrel StyleBrazed
Minimum Stud Diameter (Metric)6.35
Connection TypeCrimp
UL File NumberE23438
Maximum Conductor Size (Metric)3.31
