3M Products & Supplies

3M™ H/D Nylon Insulated with Insulation Grip Ring Tongue Terminal 123-38-NB, 1000/case - 7100163740

Sold As: 1000-Pack
SKU: 7100163740
MPN: 7100163740
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007289111
3M ID: 80601386289
MPN: 123-38-NB
$367.90 ($0.37 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Standard-style ring tongue fits around the stud

Downloads

Specifications

Maximum Operating Temperature (Celsius) UOMDegree
Ring TypeStandard
Terminal TypeRing
Insulation MaterialNylon with Insulation Grip
Minimum Stud Diameter (Imperial) UOMin
Minimum Stud Diameter (Metric)9.525
Barrel StyleBrazed
Maximum Operating Temperature (Celsius)175.0
Connection TypeCrimp
Country of OriginUnited States
Maximum Conductor Size (Metric)2.08
Minimum Stud Diameter (Metric) UOMmm
Minimum Conductor Size (Imperial)16 AWG
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Imperial)14 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
UL File NumberE23438
Minimum Conductor Size (Metric)1.31 mm²
Terminal StyleStandard
