3M Products & Supplies

3M™ H/D Nylon Insulated with Insulation Grip Ring Tongue Terminal 123-716-NB, 1000/case - 7100163741

Sold As: 1000-Pack
SKU: 7100163741
MPN: 7100163741
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007289128
3M ID: 80601386297
MPN: 123-716-NB
$375.35 ($0.38 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

Insulation MaterialNylon with Insulation Grip
Maximum Conductor Size (Imperial)12 AWG
Minimum Conductor Size (Imperial)16 AWG
Terminal TypeRing
UL File NumberE23438
Country of OriginUnited States
Minimum Stud Diameter (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
Terminal StyleStandard
Connection TypeCrimp
Minimum Stud Diameter (Metric) UOMmm
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Celsius)175.0
Minimum Conductor Size (Metric)1.31 mm²
Barrel Length (Imperial)0.25 Inch
Barrel StyleBrazed
Maximum Conductor Size (Metric)3.31
Minimum Stud Diameter (Metric)10.0
