3M Products & Supplies

3M™ H/D Nylon Insulated with Insulation Grip Ring Tongue Terminal 123-8S-NB, 1000/case - 7100163736

Sold As: 1000-Pack
SKU: 7100163736
MPN: 7100163736
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007289036
3M ID: 80611444060
MPN: 771-250-P
$318.42 ($0.32 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Standard-style ring tongue fits around the stud
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

Connection TypeCrimp
Maximum Conductor Size (Imperial)12 AWG
UL File NumberE23438
Barrel StyleBrazed
Maximum Conductor Size (Metric)3.31
Terminal StyleStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)175.0
Minimum Conductor Size (Imperial)16 AWG
Ring TypeStandard
Minimum Stud Diameter (Metric) UOMmm
Terminal TypeRing
Insulation MaterialNylon with Insulation Grip
Barrel Length (Imperial)0.25 Inch
Minimum Conductor Size (Metric)1.31 mm²
Country of OriginUnited States
Minimum Stud Diameter (Imperial) UOMin
Minimum Stud Diameter (Metric)4.0
