3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-2-48"-Red-24 Pcs, 48 in Length sticks, 24 pieces/case - 7010400858

Sold As: 24-Pack
SKU: 7010400858
MPN: 7010400858
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 10051128599393
3M ID: 80611602006
5 Digit UPC: 59939
$440.34 ($18.35 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Non-CorrosiveYes
UL Bug Temperature (Celsius)125 Degrees Celsius
Inner Diameter Before Shrink (Imperial)2.0
Overall Length (Metric)1220.0
Overall Width (Imperial) UOMin
Product ColorRed
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Inner Diameter Before Shrink (Metric)50.8
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Minimum Expanded Tubing I. D.2.0
Elongation UOM%
Shrink Ratio2:1
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Overall Length (Metric) UOMmm
Overall Width (Imperial)2.0
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter After Shrink (Metric)25.4
MaterialPolyolefin
Minimum Expanded Tubing I. D. UOMin
Mil SpecAMS-DTL-23053/5, Class 1
Overall Length (Imperial) UOMin
Tubing TypeSingle (Thin) Wall
Adhesive MaterialNone
Inner Diameter After Shrink (Imperial) UOMin
Overall Width (Metric)50.8
Overall Length (Imperial)48.0
Inner Diameter Before Shrink (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit) UOMDegree
Inner Diameter Before Shrink (Metric) UOMmm
Inner Diameter After Shrink (Metric) UOMmm
Operating Temperature (Fahrenheit)-67 °F to 275 °F
Inner Diameter After Shrink (Imperial)1.0
Flame RetardantYes
Maximum Operating Temperature (Fahrenheit)275.0
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius)135.0
UL Bug Temperature (Fahrenheit)257 Degrees Fahrenheit
