3M™ High Shear Pressure Sensitive Cover Tape 2668, PSA, New, 5.4 mm x 500 m, 0.7, 25 Roll/Case - 7100363727

Sold As: 25-Pack
SKU: 7100363727
MPN: 7100363727
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060613486
3M ID: XN400544500
$1,246.34 ($49.85 / Count)
Hurry up! Current stock:

Product Description

3M™ High Shear Pressure Sensitive Cover Tape 2668 is a transparent polyester tape with a synthetic, room temperature pressure sensitive adhesive (PSA) zone along each edge.

Features

  • Reworkable and bakeable
  • Adhesive zones help reduce the risk of adhesive contamination or contact with devices during shipping and storage
  • 300 m or 500 m rolls are available in standard widths of 5.4 mm, 9.3 mm, 13.3 mm, 21.3 mm, 25.5 mm, 37.4 mm and 49.4 mm
  • Contact 3M for information on other width options
  • Suitable for components like WLCSP
  • Works well on 3M™ Polycarbonate Carrier Tapes
Spec Sheet



Downloads

Specifications

Elongation90.0 %
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Overall Width (Imperial)0.213
Backing (Carrier) MaterialPolyester Film
Overall Length (Imperial)546.807
Minimum Sealing Temperature (Celsius)23.0
Haze Percentage6.0
Maximum Sealing Temperature (Celsius)23.0
Overall Thickness (Metric)0.061
Overall Width (Imperial) UOMin
Overall Length (Metric)500.0
ESD Material TypeConductive
Overall Thickness (Imperial)0.0024
Product UsageDiscrete Components; LEDs; Passive Components; WLCSP
Overall Thickness (Imperial) UOMin
Country of OriginSingapore
Overall Thickness (Metric) UOMmm
Maximum Sealing Temperature (Fahrenheit)73.0
Overall Length (Metric) UOMm
Minimum Sealing Temperature (Fahrenheit)73.0
Overall Width (Metric)5.4
