3M Products & Supplies

3M™ Highland™ Vinyl Insulated Fork Terminal FV10-10Q, AWG 12-10, 25/bag, 10 Bags/Case - 7010321019

Sold As: 10-Pack
SKU: 7010321019
MPN: 7010321019
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128600092
3M ID: 80611602709
5 Digit UPC: 60009
$108.26 ($10.83 / Count)
Hurry up! Current stock:

Product Description

3M™ Highland™ Vinyl Insulated Butted Seam Standard Fork is a lug connection terminal that has a wider tongue for use on free-standing studs. The terminal has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
  • Wider-tongue design for use on free-standing studs
  • Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Width (Imperial) UOMin
Maximum Insulation Outer Diameter (Imperial)0.25
Terminal StyleStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Dimension E0.84 Inch
Maximum Conductor Size (Imperial)10 AWG
Overall Length (Imperial)1.03
Barrel Inside Diameter0.135 Inch
Maximum Insulation Outer Diameter (Imperial) UOMin
Minimum Conductor Size (Metric)3.31 mm²
Packaging25 per bag
Clearance (C)0.29 Inch
Minimum Conductor Size (Imperial)12 AWG
Stud Size#10
Maximum Conductor Size (Metric)5.26 mm²
Barrel Length (Imperial)0.25 Inch
Overall Length (Imperial) UOMin
Terminal TypeFork
UL File NumberE23438
Overall Width (Imperial)0.38
Fork TypeStandard
Barrel StyleButted
Insulation MaterialVinyl
