3M Products & Supplies

3M™ Low VOC Adhesive Transfer Tape 59812LVC, Clear, 5 mil, 54 in X 60 yd, 1 Roll/Case - 7100377483

SKU: 7100377483
MPN: 7100377483
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00068060762481
3M ID: 70011146118
$992.48
Hurry up! Current stock:

Product Description

3M™ Low VOC Adhesive Transfer Tape 59812LVC represents the future of 3M™ pressure sensitive adheasive design. From the blistering heat of summer to the harsh cold of winter, vehicle interior components are designed to withstand everything the environment can throw at them. This creates bonding challenges for many hard-to-bond substrates-such as plastics, fabrics, and foams. 3M™ Low VOC Adhesive Transfer Tape 59812LVC has been engineered to perfrom through challenging conditions while offering the design flexibility to compliment your assembly process. In addition, this tape's properties ensure clean aesthetics while bonding to dissimilar materials. Don't limit your design creativity-make it a reality throught the power of 3M™ Low VOC Adhesive Transfer Tape 59812LVC.

Features

  • Long term temperature resistance up to 250˚F/121˚C
  • Short term temperature resistance up to 300˚F/149˚C
  • Enables dissimilar material bonding while delivering clean aesthetics
  • Adheres to difficult-to-bond substrates, including low surface energy (LSE) plastics, fabrics, and foams
  • Reduces VOC emissions compared to current standard 3M pressure-sensitive adhesives
  • Bonds after exposure to 100˚F (38˚C)/100% Humidity
Spec Sheet



Downloads

Specifications

Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)250.0
Primary Liner Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Metric)0.107
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius)121.0
Overall Length (Imperial)60.0
ApplicationBonding
Shelf Life730
Minimum Operating Temperature (Fahrenheit)-40.0
Product ColorTransparent
Overall Length (Metric)54.86
Minimum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Imperial)5.0
Primary Liner ColorTan
Overall Width (Imperial)54.0
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Celsius)-40.0
Primary Liner Thickness (Imperial) UOMmil
IndustriesAutomotive
Overall Width (Metric)1371.6
Primary Liner58# Polycoated Kraft Paper (PCK)
Primary Liner Thickness (Imperial)4.2
Shelf Life UOMMonth
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.13
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Imperial) UOMyd
Adhesive TypeLow VOC Acrylic
Country of OriginUnited States
Indoor/OutdoorIndoor/Outdoor
Overall Length (Metric) UOMm
