3M Products & Supplies

3M™ Membrane Switch Spacer Double Linered 9061MP, Clear, 48 in x 360 yd, 11 mil, Roll - 7010535969

SKU: 7010535969
MPN: 7010535969
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998787311
5 Digit UPC: #VALUE!
$15,711.24 each
Hurry up! Current stock:

Product Description

3M™ Membrane Switch Spacer Double Linered 9061MP features 3M™ High Performance Acrylic Adhesive 200MP, formulated for excellent shear strength, on a 7 mil PET film carrier. Adhesive withstands repeated switch actuation and forms clean edges for precise slitting and die-cutting. Heavy 94# PCK paper liners resist humidity, curling, tunneling and buckling and add stability for improved processing.

Features

  • 2 mil 3M™ Acrylic Adhesive 200MP delivers excellent shear strength, resists slippage and edge lifting
  • Liners add dimensional stability for high-speed rotary die-cutting
  • 7 mil polyester film carrier provides strength and stability
  • 11 mil double-coated spacer is ideal for withstanding repeated stress of switch actuation
  • Heavy 94# polycoated kraft (PCK) liners deliver improved handling and lay-flat
  • Adhesive resists oozing at slits and die-cuts for faster part processing
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Primary Liner Thickness (Imperial)7.0
Secondary Liner Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)11.0
Face Side Adhesive Thickness (Imperial)2.0
Backing (Carrier) Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial)2.0
Overall Length (Imperial) UOMyd
Overall Length (Metric)329.18
Secondary Liner94# Polycoated Kraft Paper
Total Tape Thickness without Liner (Imperial) UOMmil
Primary Liner94# Polycoated Kraft Paper
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Primary Liner Thickness (Metric)0.18
Minimum Operating Temperature (Fahrenheit)-40.0
Back Side Adhesive Thickness (Metric) UOMmm
Secondary Liner ColorWhite
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Product ColorTransparent
Backing (Carrier) MaterialPolyester Film
Secondary Liner Thickness (Imperial)7.0
Back Side Adhesive Thickness (Imperial) UOMmil
Secondary Liner Thickness (Metric)0.18
Secondary Liner Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)400.0
Overall Width (Imperial)48.0
Back Side Adhesive Thickness (Metric)0.05
Face Side Adhesive Thickness (Metric)0.05
Overall Length (Imperial)360.0
Total Tape Thickness without Liner (Metric)0.28
Primary Liner Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)7.0
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Overall Width (Metric)1219.2
Backing (Carrier) Thickness (Metric)0.18
Face Side Adhesive Thickness (Metric) UOMmm
Primary Liner ColorWhite
Overall Length (Metric) UOMm
Adhesive TypeHigh Performance Acrylic Adhesive 200MP
Shelf Life UOMMonth
