3M™ Non-Insulated Brazed Seam Ring Tongue Terminal 15-500S-W, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163760

Sold As: 1000-Pack
SKU: 7100163760
MPN: 7100163760
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007291107
3M ID: 80601388285
MPN: 15-500S-W
$614.36 ($0.61 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Ring TypeStandard
UL File NumberE23438
Maximum Conductor Size (Imperial)6 AWG
Insulation MaterialNon-insulated
Minimum Conductor Size (Metric)13.3 mm²
Barrel StyleBrazed
Barrel Length (Imperial)0.25 Inch
Terminal TypeRing
Terminal StyleStandard
Minimum Conductor Size (Imperial)6 AWG
Minimum Stud Diameter (Imperial) UOMin
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Connection TypeCrimp
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Stud Diameter (Metric)12.7
Maximum Conductor Size (Metric)13.3
Country of OriginUnited States
