3M™ Non-Insulated Butted Seam Ring Tongue Terminal, 11-14S, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163485

Sold As: 1000-Pack
SKU: 7100163485
MPN: 7100163485
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007279228
3M ID: 80601375936
MPN: 11-14S
$111.54 ($0.11 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Connection TypeCrimp
Minimum Stud Diameter (Imperial) UOMin
Minimum Conductor Size (Imperial)22 AWG
Barrel StyleBrazed
Minimum Stud Diameter (Metric)6.35
Minimum Stud Diameter (Metric) UOMmm
Terminal TypeRing
Country of OriginUnited States
Minimum Conductor Size (Metric)0.326 mm²
Ring TypeStandard
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation MaterialNon-insulated
UL File NumberE23438
Maximum Operating Temperature (Celsius)175.0
Maximum Conductor Size (Metric)0.823
Terminal StyleStandard
Maximum Conductor Size (Imperial)18 AWG
Maximum Operating Temperature (Celsius) UOMDegree
Barrel Length (Imperial)0.25 Inch
