3M Products & Supplies

3M™ Non-Insulated Butted Seam Ring Tongue Terminal 12-14S, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163579

Sold As: 1000-Pack
SKU: 7100163579
MPN: 7100163579
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007283249
3M ID: 80601380167
MPN: 12-14S
$111.54 ($0.11 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Standard-style ring tongue fits around the stud
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Insulation MaterialNon-insulated
Barrel StyleBrazed
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Conductor Size (Metric)1.31 mm²
Minimum Stud Diameter (Imperial) UOMin
Connection TypeCrimp
UL File NumberE23438
Country of OriginUnited States
Terminal StyleStandard
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric)6.35
Minimum Stud Diameter (Metric) UOMmm
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Imperial)16 AWG
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Metric)2.08
Ring TypeStandard
Terminal TypeRing
