3M Products & Supplies

3M™ Non-Insulated Butted Seam Ring Tongue Terminal 12-4S, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163573

Sold As: 1000-Pack
SKU: 7100163573
MPN: 7100163573
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007283140
3M ID: 80601380068
MPN: 12-4S
$73.37 ($0.07 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Standard-style ring tongue fits around the stud
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)

Downloads

Specifications

RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Conductor Size (Imperial)14 AWG
Minimum Stud Diameter (Metric) UOMmm
Minimum Stud Diameter (Imperial) UOMin
Minimum Conductor Size (Imperial)16 AWG
UL File NumberE23438
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Stud Diameter (Metric)2.5
Connection TypeCrimp
Country of OriginUnited States
Maximum Conductor Size (Metric)2.08
Terminal StyleStandard
Barrel Length (Imperial)0.25 Inch
Maximum Operating Temperature (Celsius)175.0
Minimum Conductor Size (Metric)1.31 mm²
Insulation MaterialNon-insulated
Ring TypeStandard
Barrel StyleBrazed
Terminal TypeRing
