3M Products & Supplies

3M Nylon 6/6 Screw-Mount Cable Tie CT8NT50S-M, 8.60 in x 0.18 in x 0.06 in, Natural, 1000/Bag, 10,000/Case

Sold As: 10000-Pack
SKU: 7100019537
MPN: CT8NT50S-M
For an accurate lead time please contact us
UPC: 00051128592984
3M ID: 80611469570
5 Digit UPC: 59298
$1,093.67 ($0.11 / Count)
Hurry up! Current stock:

Product Description

Legal Disclaimer

  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Manufacturing Origin: USA

Overview

  • Self-locking head assures locking in any position
  • 3M™ Screw-Mount Ties allow controlled positioning of standard and heavy-duty cables. These weather-resistant ties are made of nylon 6/6 to withstand the harsh environments. The ends of the cable ties possess curved tips that allow faster threading and installation. Their tough construction withstands a maximum operating temperature range of -40 to 185 degrees F (-40 to 85 degrees C).
  • Allows controlled positioning of standard and heavy-duty cable
  • 3M™ Screw-Mount Ties feature curved tips and a self-locking head that assures locking in any position to bind the bundle wires or cables easily. These standard, easy-to-use ties are suitable to use with most standard tensioning/cutoff tools for fast production line fastening. They use screws, bolts or rivets for secure mounting onto walls and structures. They are commonly used in more demanding commercial and industrial jobs when extra strength is required. UL Listed, EU RoHS Compliant and Plenum-rated.
  • Curved tips offer faster threading and installation
  • Measures 0.18 in x 8.6 in
  • Withstands a wide temperature range of -40 to 185 degrees F (-40 to 85 degrees C)
  • Bind the bundle of wires or cables easily
  • Tough construction of natural color nylon 6/6 for indoor applications
  • Tensile strength of 50 lbs
Spec Sheet



Specifications

Cable Tie Length203 mm
Width (Metric)4.6 mm
Length (Metric)218 mm
Minimum Installation Temperature (Celsius)-20 Degree Celsius
Solution forLong-haul/Metro Loop Network: CO/POP, Long-haul/Metro Loop Network: Outdoor, Wireless Network: Backhaul, Wireless Network: Infrastructure Accessories
Operating Temperature Range (Fahrenheit)-40 °F to 185 °F
Flammability RatingUL 94 V-2
Cable Length (metric)228.6 mm
Plenum RatedRoHS 2011/65/EU Compliant, Yes
Maximum Operating Temperature85 Degree Celsius
Tensile StrengthStandard (50 lb)
Maximum Operating Temperature (Fahrenheit)185 Degree Fahrenheit
RoHS 2011/65/EU CompliantRoHS 2011/65/EU Compliant, Yes
UV ResistantNo, UV Resistant
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Thickness (Metric)1.4 mm
Operating Temperature (Celsius)85 Degree Celsius
Maximum Operating Temperature (Celsius)85 Degree Celsius
Width0.18 Inch
Approximate Length8
Tensile Strength (metric)22.68 kg
Minimum Installation Temperature (Fahrenheit)-4 Degree Fahrenheit
Length8.6 Inch
Cable Length8 Inch
Product TypeCable Tie
Trademark3M
Thickness0.054 Inch
Operating Temperature (Fahrenheit)185 Degree Fahrenheit
Operating Temperature Range (Celsius)-40 °C to 85 °C
ColorNatural
Maximum Bundle Diameter (metric)50.8 mm
Minimum Bundle Diameter (metric)1.6 mm
Cable Management ProductsCable Ties
MaterialNylon 6/6
Maximum Bundle Diameter2 Inch
TypeStandard
Brand3M™
Agency ApprovalsUL, UL Listed 62275 Type 21
