3M Products & Supplies

3M™ Polyester Film Electrical Tape 1350F-1, Yellow .5 x 72 YD LOG, 3" Paper Core, 24 Rolls/Case - 7000132841

Sold As: 24-Pack
SKU: 7000132841
MPN: 7000132841
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051125652353
3M ID: 80611088834
5 Digit UPC: 65235
$378.49 ($15.77 / Count)
Hurry up! Current stock:

Product Description

3M™ Polyester Film Electrical Tape 1350F-1 tape is a yellow, white, or black, UL recognized flame retardant, 2.5-mil (0.064 mm) thick tape composed of a 1-mil (0.025 mm) polyester film backing coated on one side with a non-corrosive, acrylic pressure-sensitive adhesive.

Features

  • Nominal thickness: 0.064 mm (2.5 mil)
  • Printable
  • Pressure-sensitive acrylic adhesive with polyester film backing
  • UL Recognized flame retardant
  • UL Recognized and CSA certified 130°C temperature rating
  • 5 year shelf-life when stored per 3M recommended conditions
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Electrolytic Corrosion Factor1.0
Tape GradeProfessional
Total Tape Thickness without Liner (Metric) UOMmm
Dielectric Strength5500.0
Backing (Carrier) MaterialPolyester
Minimum Operating Temperature (Celsius) UOMDegree
Product ColorYellow
Shelf Life UOMYear
Adhesive TypeAcrylic
Specifications MetRoHS 2011/65/EU, UL 510, UL Listed
Maximum Operating Temperature (Celsius) UOMDegree
Insulation Resistance> 10^6 megohms
Dielectric Strength UOMV
Total Tape Thickness without Liner (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius)0.0
Overall Width (Metric)12.7
Overall Width (Imperial) UOMin
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)266.0
Total Tape Thickness without Liner (Metric)0.064
Product MarketsElectrical Equipment Manufacturing
Maximum Operating Temperature (Celsius)130.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)0.5
Total Tape Thickness without Liner (Imperial)2.5
ApplicationInsulation
Minimum Operating Temperature (Fahrenheit)32.0
