3M Products & Supplies

3M Acetate Cloth Electrical Tape 28, 3/4 in x 36 yd, Translucent - 62-GRAY-3/4"X36YD

Sold As: 12-Pack
SKU: 7000132705
MPN: 62-GRAY-3/4"X36YD
Lead Time: 14 working days.
UPC: 00051138496166
3M ID: 80610881957
5 Digit UPC: 49616
$1,594.01 ($132.83 / Count)
Hurry up! Current stock:

Product Description

Legal Disclaimer

  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.
  • Manufacturing Origin: USA
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.

Overview

  • Resin- and varnish-absorptive black acetate cloth backing
  • Acetate cloth tape offering excellent conformability in coil-wrapping applications up to 105°C
  • Aggressive rubber resin adhesive with a resin- and varnish-absorptive black acetate cloth backing.
  • Excellent absorption of electrical insulating resins and varnishes
  • 3/4 in x 36 yd
  • 3M™ Acetate Cloth Electrical Tape 28 is an aesthetically pleasing acetate cloth tape offering excellent conformability in coil-wrapping applications up to 105°C plus excellent absorption of electrical insulating resins and varnishes.
  • Aggressive rubber resin adhesive
Spec Sheet



Specifications

ColorTranslucent
Operating Temperature (Celsius)180°
Electrolytic Corrosion Factor1
Agency ApprovalsFlame Retardant, UL Recognized
Backing MaterialPTFE Film
Operating Temperature Range (Celsius)0 °C to 180 °C
Length36 Linear Yard
Rolls per Case12
Operating Temperature Range (Fahrenheit)32 °F to 356 °F
Thickness (Metric)0.1 mm
Length (Metric)32.9 m
Dielectric Breakdown9500 Volt
Adhesion to Steel oz/in (N/100 mm)30 (32)
Elongation at Break200%
Flame ResistantYes
Width0.75 Inch
Thickness4 mil
Backing Thickness (metric)2 mil
Product MarketsElectrical Equipment Manufacturing
Breaking Strength20 lb/in
Product TypePTFE Film Tape
Printable TapeYes
UL 510Yes
RoHS 2011/65/EU CompliantYes
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation Resistance1 x 10^6 megohms
National Stock Number5970000514041
Tape TypeElectrical Insulating Tapes for Equipment Manufacturing
Dielectric Strength9500 Volt
Adhesive MaterialSilicone
