3M Products & Supplies

3M Acetate Cloth Electrical Tape 28, 3/4 in x 36 yd, Translucent - 63-3/4"X36YD

Sold As: 12-Pack
SKU: 7010398763
MPN: 63-3/4"X36YD
Lead Time: 15 working days.
UPC: 00051138495022
3M ID: 80610880819
5 Digit UPC: 49502
$1,366.97 ($113.91 / Count)
Hurry up! Current stock:

Product Description

Overview

  • Aggressive rubber resin adhesive
  • Excellent absorption of electrical insulating resins and varnishes
  • 3M™ Acetate Cloth Electrical Tape 28 is an aesthetically pleasing acetate cloth tape offering excellent conformability in coil-wrapping applications up to 105°C plus excellent absorption of electrical insulating resins and varnishes.
  • Aggressive rubber resin adhesive with a resin- and varnish-absorptive black acetate cloth backing.
  • Resin- and varnish-absorptive black acetate cloth backing
  • 3/4 in x 36 yd
  • Acetate cloth tape offering excellent conformability in coil-wrapping applications up to 105°C

Legal Disclaimer

  • Manufacturing Origin: USA
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
Spec Sheet



Specifications

ColorTranslucent
Agency ApprovalsFlame Retardant, UL Recognized
Adhesive MaterialAcrylic
Backing MaterialPTFE Film
Length (Metric)32.9 m
Length36 Linear Yard
Rolls per Case12
Width0.75 Inch
Flame ResistantYes
Operating Temperature (Celsius)155°
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Breaking Strength20 lb/in
Elongation at Break200%
Adhesion to Steel oz/in (N/100 mm)35 (38)
Operating Temperature Range (Celsius)0 °C to 155 °C
Dielectric Strength9500 Volt
Insulation Resistance1 x 10^6 megohms
Operating Temperature Range (Fahrenheit)32 °F to 307 °F
Electrolytic Corrosion Factor1
Thickness3.5 mil
Tape TypeElectrical Insulating Tapes for Equipment Manufacturing
RoHS 2011/65/EU CompliantYes
UL 510Yes
Backing Thickness (metric)2 mil
National Stock Number5970011188457
Product MarketsElectrical Equipment Manufacturing
Dielectric Breakdown9500 Volt
Thickness (Metric)0.09 mm
Product TypePTFE Film Tape
