3M Products & Supplies

3M™ PTFE Film Tape 5480, Gray, 1 in x 36 yd, 3.7 mil, 7 Roll/Case - 7100221271

Sold As: 9-Pack
SKU: 7100221271
MPN: 7100221271
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00638060406496
3M ID: 70007543617
5 Digit UPC: 40649
$1,276.25 ($141.81 / Count)
Hurry up! Current stock:

Product Description

3M™ PTFE Skived Film Tape 5480 uses a skived, polytetrafluoroethylene (PTFE), conformable film backing. This tape offers an extremely low coefficient of friction which, in combination with a pressure sensitive silicone adhesive, creates a smooth, non-stick surface over a variety of substrates to assist in the movement of web materials in many types of roll-wrap applications.

Features

  • Non-stick PTFE film provides an exceptionally slick surface for easy clean-up
  • Excellent chemical resistance enables tape to withstand challenging applications
  • Wide temperature range for performance on heated machinery and equipment
  • Silicone adhesive provides clean removal from a variety of surfaces
  • Skived 3M™ PTFE Film Tapes are more conformable than typical extruded PTFE film tapes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Adhesive TypeSilicone
Total Tape Thickness without Liner (Imperial)3.7
Overall Length (Metric)32.918
Tensile Strength (Metric)46.1
Overall Length (Metric) UOMm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric)0.093
Backing (Carrier) Thickness (Metric)0.05
Minimum Operating Temperature (Fahrenheit)-65.0
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial) UOMmil
Tensile Strength (Imperial)27.0
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Imperial)2.0
Overall Length (Imperial)36.0
Overall Width (Imperial)1.0
Overall Width (Metric)25.4
Tensile Strength (Metric) UOMN/100mm
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)500.0
Product ColorGray
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)260.0
Minimum Operating Temperature (Celsius)-54.0
