3M Products & Supplies

3M™ Ring Tongue, Nylon Insulated Brazed Seam 8 AWG, 94756, 14-500S-WN - 7010349246

Sold As: 10-Pack
SKU: 7010349246
MPN: 7010349246
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007947561
3M ID: 80611252562
MPN: 94756
$274.20 ($27.42 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Standard-style ring tongue fits around the stud
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Downloads

Specifications

Minimum Stud Diameter (Imperial) UOMin
Maximum Operating Temperature (Celsius)175.0
Minimum Stud Diameter (Metric)12.7
UL File NumberE23438
Terminal TypeRing
Barrel StyleBrazed
Insulation MaterialNylon
Ring TypeStandard
Country of OriginUnited States
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Imperial)8 AWG
Minimum Conductor Size (Imperial)8 AWG
Maximum Conductor Size (Metric)8.37
Stud Size0.5 in
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Connection TypeCrimp
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Stud Diameter (Metric) UOMmm
Terminal StyleStandard
Minimum Conductor Size (Metric)8.37 mm²
