3M Products & Supplies

3M™ Ring Tongue, Nylon Insulated w/Insulation Grip 16-14, 94728, 12-10-NB - 7010319490

Sold As: 10-Pack
SKU: 7010319490
MPN: 7010319490
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00054007947288
3M ID: 80611252281
MPN: 94728
$245.06 ($24.51 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Standard-style ring tongue fits around the stud
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Country of OriginUnited States
Stud Size0.19 in
Terminal StyleStandard
UL File NumberE23438
Minimum Stud Diameter (Metric) UOMmm
Barrel StyleBrazed
Minimum Stud Diameter (Metric)5.0
Barrel Length (Imperial)0.25 Inch
Maximum Conductor Size (Imperial)14 AWG
Connection TypeCrimp
Maximum Operating Temperature (Celsius)175.0
Minimum Conductor Size (Imperial)16 AWG
Maximum Conductor Size (Metric)2.08
Terminal TypeRing
Minimum Conductor Size (Metric)1.31 mm²
Insulation MaterialNylon with Insulation Grip
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Stud Diameter (Imperial) UOMin
Ring TypeStandard
