3M Products & Supplies

3M™ Scotch-Weld™ Epoxy Adhesive DP420, Off-White, 400 mL Duo-Pak, 6/case - 7100002516

Sold As: 6-Pack
SKU: 7100002516
MPN: 7100002516
For an accurate lead time please contact us
UPC: 021200878336
3M ID: 62328035308
5 Digit UPC: 87833
$1,239.02 ($206.50 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotch-Weld™ Epoxy Adhesive DP420 is a toughened, two-part epoxy structural adhesive that provides good strength along with high impact and fatigue resistance to meet demanding bonding challenges. 3M™ Scotch-Weld Epoxy Adhesive DP420 can replace mechanical fasteners, screws, rivets and spot welds in many applications.

Features

  • High peel and shear strength maintains lasting bond at high and low temperatures
  • Adhesive cures at room temperature, making it a convenient and easy to use solution for challenging applications
  • Toughened for impact and fatigue resistance
  • Reaches high strength quickly with heat cure
  • 20 minute work life provides time for positioning and adjustment

Downloads

Specifications

Adhesive TypeEpoxy
Flame RetardantUL94 HB
Product TypeEpoxy Adhesive
Shear Strength4500 psi
Hardness75-80 Shore D
Product ColorOff-white
Physical FormFlowable Liquid
Viscosity Range (cps) at Room TemperatureBase: 190,000-270,000, Accelerator: 60,000-130,000 - 30,000
ApplicationBonding - Hard Disk Drive Component Assembly - Potting
Product FormCartridge
Storage Temperature60-80 F (16-27 C)
Specific Gravity1.13
Container Size (Imperial)13.52 fl oz (US)
Product NumberDP420
Storage Temperature (Celsius)16°C - 27°C
Open Time20 minutes @ 72 F (22 C)
Substrate 1Smooth - Metal - Wood - Plastic, Easy-to-Bond (HSE) - Glass & Ceramics - Paint - Glass
Full Cure Time24 Hours @ 72 F (22 C)
SubstrateMetal - Stone - HSE Plastics and Glass - Wood - Ceramic - Metal (Unpainted) - Glass - Paints (Powder Coat, Painted Metal, Composite Panel) - Plastics: HSE, MSE (ABS, Acrylic, Polycaronate, Nylon) - Paint - Smooth - Glass & Ceramics
ViscositySelf-Leveling
Indoor/OutdoorBoth
Set Time10 to 30 Minute - 2 Hour
Substrate 2Smooth - Paint - Glass & Ceramics - Wood - HSE Plastics and Glass - Metal - Ceramic - Glass - Stone - Metal (Unpainted) - Plastics: HSE, MSE (ABS, Acrylic, Polycaronate, Nylon) - Paints (Powder Coat, Painted Metal, Composite Panel)
Volume (Imperial)13.53 fl oz
Container Size (Metric)400 ml
Work Time15-30 Minutes
Color FamilyWhite
