3M Products & Supplies

3M™ Scotch-Weld™ Epoxy Adhesive DP420, Off-White, 50 mL Duo-Pak, 12/case - 7100148736

Sold As: 12-Pack
SKU: 7100148736
MPN: 7100148736
For an accurate lead time please contact us
UPC: 638060089781
3M ID: 62328014360
5 Digit UPC: 8978
$465.49 ($38.79 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotch-Weld™ Epoxy Adhesive DP420 is a toughened, two-part epoxy structural adhesive that provides good strength along with high impact and fatigue resistance to meet demanding bonding challenges. 3M™ Scotch-Weld Epoxy Adhesive DP420 can replace mechanical fasteners, screws, rivets and spot welds in many applications.

Features

  • High peel and shear strength maintains lasting bond at high and low temperatures
  • Toughened for impact and fatigue resistance
  • 20 minute work life provides time for positioning and adjustment
  • Adhesive cures at room temperature, making it a convenient and easy to use solution for challenging applications
  • Reaches high strength quickly with heat cure

Downloads

Specifications

Physical FormFlowable Liquid
SubstratePaint - Ceramic - Plastics: HSE, MSE (ABS, Acrylic, Polycaronate, Nylon) - HSE Plastics and Glass - Smooth - Stone - Glass & Ceramics - Metal (Unpainted) - Metal - Wood - Paints (Powder Coat, Painted Metal, Composite Panel) - Glass
Product TypeEpoxy Adhesive
Storage Temperature60-80 F (16-27 C)
Design ChallengesNoise Vibration & Harshness Control NVH - Impact & Shock Absorption
Indoor/OutdoorBoth
Product FormCartridge
Work Time15-30 Minutes
ViscositySelf-Leveling
Substrate 2Smooth - Paint - Glass & Ceramics - HSE Plastics and Glass - Metal - Wood
Flame RetardantUL94 HB
Color FamilyWhite
Container Size (Imperial)1.69 fl oz (US)
Viscosity Range (cps) at Room Temperature30,000
Substrate 1Glass - Metal - Smooth - Plastic, Easy-to-Bond (HSE) - Paint - Wood - Glass & Ceramics
Container Size (Metric)50 ml
Product ColorOff-white
Adhesive TypeEpoxy
Open Time20 minutes @ 72 F (22 C)
Product NumberDP420
Set Time10 to 30 Minute
Full Cure Time24 Hours @ 72 F (22 C)
Storage Temperature (Celsius)16°C - 27°C
Volume (Imperial)1.69 fl oz
Shear Strength4500 psi
