3M Scotchcast Electrical Resin 8N, part A, 40 lbs/pail

SKU: 7100149401
MPN: 7100149401
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128613634
3M ID: 80611616931
5 Digit UPC: 61363
Shelf Life: 730 Days
Country of Origin: USA
Manufacturer: 3M
Color: Clear Amber
$1,729.99 each
Hurry up! Current stock:
Product Description
3M Scotchcast Electrical Resin 8N is a 2 part, liquid resin that is useful for electronic and electrical applications requiring the highest level of protection in the toughest environments. This unfilled epoxy based resin has a low viscosity property, which makes it easy to infuse on any surface. It is useful for applications that include filling, patching, insulating and more.3M Scotchcast Electrical Resin 8N has a low gel point rating to ensure curing at room temperature. The high tensile strength of the resin exhibits a semi flexible and good adhesion property after curing. It is ideal for applications that need excellent thermal shock and mechanical shock resistance. The high dielectric strength offers excellent electrical insulating property to the resin. It has a high flash point, helping prevent any fire hazard in electrical components due to quick ignition. Since the resin exhibits a hydrolytic stability property, it minimizes quick chemical decomposition, thus providing long lasting usage. RoHS 2011/65/EU Compliant.

Extra Details

  • 68 Shore D hardness
  • Chemical- and moisture-resistant
  • Elongates 75% longer than its original size for easy insulation or wrapping
  • Has 30-minute gel time at 140 ?? (60 ??)
  • MIL-I-16923E, MIL-I-16923G Certified and RoHS 2011/65/EU Compliant
  • Useful for coating coils, transformers, motors, modules, electrical and electronic components
  • Withstands a temperature range of 32 to 266 ?? (0 to 130 ??)

Data Sheet

  1. Tech Data Sheet
  2. Safety Data Sheet
