3M Products & Supplies

3M™ Scotchlok™ Butt Connector, Vinyl Insulated Butted Seam MVU18BCK, 22-18 AWG, 1000/Case - 7000132243

Sold As: 1000-Pack
SKU: 7000132243
MPN: 7000132243
For an accurate lead time please contact us
UPC: 00054007013150
3M ID: 80610039358
5 Digit UPC: 1315
$307.12 ($0.31 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Vinyl Insulated Butted Seam Butt Connector ensures an ideal fit while offering reliable and safe performance. The connector has a vinyl-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Built-in wire stop for correct positioning
  • Vinyl-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, polyvinyl chloride sleeve offers easy insertion of wires
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Maximum Conductor Size (Metric)1 mm²
Minimum Conductor Size (Imperial)22 AWG
Minimum Conductor Size (Metric).34 mm²
Maximum Operating Temperature (Celsius)105.0
Overall Length (Imperial) UOMin
Connector TypeButt
Insulation MaterialVinyl
Overall Length (Imperial)1.0
Maximum Operating Temperature (Celsius) UOMDegree
Product ColorRed
Maximum Conductor Size (Imperial)18 AWG
Body MaterialCopper Alloy
