3M Products & Supplies

3M™ Scotchlok™ Locking Fork Nylon Insulated, 100/bottle, MNG14-10FLX, spring-like tongue firmly fits around the stud, 500/Case - 7000133360

Sold As: 100-Pack
SKU: 7000133360
MPN: 7000133360
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128587973
3M ID: 80611464431
5 Digit UPC: 58797
$112.37 ($1.12 / Count)
Hurry up! Current stock:

Product Description

3M™ Locking Fork Terminal has a spring-like tongue to securely lock around the stud. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Spring-like tongue firmly fits around the stud
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

Country of OriginUnited States
Overall Width (Metric) UOMmm
Maximum Recommended Voltage Rating600.0
Overall Length (Imperial)0.89
UL File NumberE23438
Units per Case500.0
Barrel StyleButted
Maximum Insulation Outer Diameter (Metric) UOMmm
Maximum Insulation Outer Diameter (Metric)3.7
Maximum Insulation Outside Diameter0.145 in
Overall Length (Metric) UOMmm
Barrel Inside Diameter0.090 Inch
Packaging100 per bottle
Minimum Conductor Size (Imperial)16 AWG
Fork TypeLocking
Overall Width (Imperial) UOMin
Maximum Lock Width0.35 Inch
Maximum Recommended Voltage Rating UOMV
Product ColorBlue
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation MaterialNylon with Insulation Grip
Maximum Operating Temperature (Fahrenheit)221.0
Overall Length (Imperial) UOMin
Maximum Conductor Size (Imperial)14 AWG
Minimum Conductor Size (Metric)1.31 mm²
Stud Size#10
Maximum Insulation Outer Diameter (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit) UOMDegree
Clearance (C)0.25 Inch
Maximum Conductor Size (Metric)2.08 mm²
Dimension E0.71 Inch
Maximum Operating Temperature (Celsius) UOMDegree
Overall Length (Metric)22.6
Maximum Operating Temperature (Celsius)105.0
Terminal StyleLocking
Maximum Insulation Outer Diameter (Imperial)0.17
MaterialPlastic
Overall Width (Imperial)0.32
Overall Width (Metric)8.12
