3M Products & Supplies

3M™ Scotchlok™ Male Disconnect, Fully Nylon Insulated Butted Seam MNU18-250DMIK, 22-18 AWG, 1/Case - 7000057725

Sold As: 1000-Pack
SKU: 7000057725
MPN: 7000057725
For an accurate lead time please contact us
UPC: 00054007022992
3M ID: 80610057764
5 Digit UPC: 2299
$585.19 ($0.59 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 12-10 AWG and has case quantities of 500 per case.

Features

  • Nylon-insulated, butted-seam barrel offers easy insertion of wires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Allows for quick and easy disconnect of wires
  • This male disconnect terminal offers excellent holding force
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Terminal StyleFully Insulated
Overall Width (Imperial) UOMin
Barrel Length (Imperial)0.25 Inch
Maximum Operating Temperature (Celsius)105.0
Overall Length (Imperial) UOMin
Insulation MaterialNylon
Minimum Conductor Size (Imperial)22 AWG
Overall Length (Imperial)0.95
Units per Case1000.0
Maximum Conductor Size (Imperial)18 AWG
Operating Temperature Range (Celsius)-40 °C to 105 °C
Minimum Conductor Size (Metric).34 mm²
Connection Width (Metric) UOMmm
Maximum Insulation Outer Diameter (Imperial)0.145
Male Tab Width (W')0.25 Inch
Barrel StyleButted
Insulation ColorRed
Overall Width (Imperial)0.44
Connection Width (Imperial) UOMin
Maximum Insulation Outer Diameter (Metric)3.7
Connection Width (Imperial)0.25
Fastener OrientationMale
Maximum Operating Temperature (Celsius) UOMDegree
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Diameter (D)0.3 Inch
Interrupt Free ShiftingNo
Maximum Insulation Outer Diameter (Imperial) UOMin
Tab Width0.250
Overall Diameter (Imperial)0.3
Maximum Insulation Outer Diameter (Metric) UOMmm
Overall Diameter (Imperial) UOMin
Connection Width (Metric)6.35
Packaging1000 per bulk box
Grease Filling Against CorrosionNo
UL File NumberE70512
Terminal TypeDisconnect
Barrel Inside Diameter0.065 Inch
Disconnect TypeMale
Pad Width0.25
Maximum Conductor Size (Metric)1 mm²
Max. Number of Cores1.0
