3M Products & Supplies

3M™ Scotchlok™ Male Disconnect, Heat Shrink Fully Nylon Insulated Butted Seam MNHU14-250DMIK, 16-14 AWG, 250/Case - 7100164279

Sold As: 250-Pack
SKU: 7100164279
MPN: 7100164279
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007063414
3M ID: 80610530240
5 Digit UPC: 6341
$243.48 ($0.97 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • When crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and salt
  • Withstands a maximum temperature of 221 degrees F (105 degrees C)
  • This male disconnect terminal offers excellent holding force
  • Mates with 0.25-in wide female tab
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Barrel Inside Diameter0.085 Inch
Overall Diameter (Imperial) UOMin
Pad Width0.25
Insulation MaterialHeat Shrink
Disconnect TypeMale
Connection Width (Metric)6.35
Overall Length (Imperial)1.2
Minimum Conductor Size (Imperial)16 AWG
Packaging250 per bulk box
Connection Width (Imperial) UOMin
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Units per Case250.0
Terminal TypeDisconnect
Fastener OrientationMale
Overall Width (Imperial)0.44
Male Tab Width (W')0.25 Inch
Tab Width0.250
Minimum Conductor Size (Metric)1.5 mm²
Overall Diameter (Imperial)0.3
Barrel StyleButted
Connection Width (Imperial)0.25
Diameter (D)0.3 Inch
Barrel Length (Imperial)0.25 Inch
Overall Length (Imperial) UOMin
Overall Width (Imperial) UOMin
Maximum Conductor Size (Metric)2.5 mm²
Terminal StyleFully Insulated
Maximum Conductor Size (Imperial)14 AWG
Connection Width (Metric) UOMmm
