3M Products & Supplies

3M™ Scotchrap™ Vinyl Corrosion Protection Tape 51, 1 in x 100 ft, Printed, Black, 24 rolls/Case - 7000132742

Sold As: 24-Pack
SKU: 7000132742
MPN: 7000132742
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007428022
3M ID: 80610927727
5 Digit UPC: 42802
$687.39 ($28.64 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchrap™ Tape 51 is a premium grade, 20 mil thick, all weather tape with PVC backing. It withstands temperatures of 55 to 176 °F ( 48 to 80 °C) and resists abrasion and punctures. This printed, high tack, adhesive tape is corrosion and impact resistant, making it suitable for use on metal piping systems, conduits and fittings both above and below ground.

Features

  • Withstands a wide temperature range of -55 to 176 °F (-48 to 80 °C)
  • Pressure-sensitive, rubber adhesive provides optimized adherence
  • RoHS 2011/65/EU Compliant
  • Black PVC backing offers good mechanical strength and electrical insulation properties
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginUnited States
Specifications MetRoHS 2011/65/EU
Overall Width (Metric)25.4
Overall Thickness (Imperial)0.02
Maximum Installation Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius)-48.0
Total Tape Thickness without Liner (Imperial)20.0
UV ResistantYes
Maximum Installation Temperature (Celsius)65.0
Adhesion Strength30.0
Overall Thickness (Metric) UOMmm
Backing Thickness (Metric)0.5
Maximum Operating Temperature (Fahrenheit) UOMDegree
Backing Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Tape TypeCorrosion Protection
Overall Width (Metric) UOMmm
Product ColorBlack
Chemical ResistantYes
Maximum Installation Temperature (Fahrenheit)150.0
Overall Thickness (Imperial) UOMin
Overall Length (Metric) UOMm
Shelf Life UOMYear
Maximum Installation Temperature (Celsius) UOMDegree
Overall Length (Imperial) UOMft
Electrolytic Corrosion Factor0.9
Overall Width (Imperial)1.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial)100.0
Backing Thickness (Imperial)19.7
Backing Thickness (Imperial) UOMmil
Adhesive TypeRubber
Total Tape Thickness without Liner (Metric)0.5
Overall Length (Metric)30.5
Total Tape Thickness without Liner (Imperial) UOMmil
Minimum Operating Temperature (Celsius) UOMDegree
Overall Thickness (Metric)0.5
Maximum Operating Temperature (Celsius) UOMDegree
Elongation at Break150 %
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Celsius)80.0
Backing MaterialVinyl
Maximum Operating Temperature (Fahrenheit)176.0
Performance LevelProfessional Grade
Minimum Operating Temperature (Fahrenheit)-55.0
