3M Products & Supplies

3M™ Squeak Reduction Tape 5430, Transparent, 1/2 in x 36 yd, 7.4 mil, 16 Rolls/Case - 7100226654

Sold As: 48-Pack
SKU: 7100226654
MPN: 7100226654
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00638060406373
3M ID: 70007543500
5 Digit UPC: 40637
$6,756.32 ($140.76 / Count)
Hurry up! Current stock:

Product Description

3M™ Squeak Reduction Tape 5430 is a transparent UHMW polyethylene film tape with an acrylic adhesive. It is commonly used to control squeaks and rattles due to vibration or wear of metal and plastic parts.

Features

  • Excellent adhesion to many painted metal and plastic surfaces
  • Low coefficient of friction for applications requiring slick surface
  • Liner ideal for fabrication and die cutting into various lengths and shapes
  • High-tack acrylic adhesive provides strong initial bond for fast results and less down time
  • UHMW polyethylene backing reduces and helps eliminate noise and vibration
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Tensile Strength (Metric) UOMN/100mm
Adhesion Strength (Metric)82.0
Minimum Operating Temperature (Fahrenheit)-30.0
Product ColorTransparent
Overall Length (Metric) UOMm
Overall Width (Metric)12.7
Overall Width (Metric) UOMmm
Tensile Strength (Metric)74.5
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) Thickness (Imperial)5.1
Backing (Carrier) Thickness (Metric) UOMmm
Adhesion Strength75.0
Overall Length (Imperial)36.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric)32.918
Maximum Operating Temperature (Celsius)107.0
Tensile Strength (Imperial)40.0
Overall Length (Imperial) UOMyd
Adhesive TypeAcrylic
Maximum Operating Temperature (Fahrenheit)225.0
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Metric)0.13
Maximum Operating Temperature (Fahrenheit) UOMDegree
Tensile Strength (Imperial) UOMlb/in
Overall Width (Imperial)0.5
Total Tape Thickness without Liner (Imperial)7.4
Backing (Carrier) MaterialPolyethylene
Elongation at Break420%
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Metric)0.19
Adhesion Strength (Metric) UOMN/100mm
