3M Products & Supplies

3M™ Thin-Wall Flexible Polyolefin Adhesive-Lined Heat Shrink Tubing EPS400 0.35" Black 6-in pieces, 10 Packs/Case - 7010293960

Sold As: 10-Pack
SKU: 7010293960
MPN: 7010293960
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128600726
3M ID: 80611603343
5 Digit UPC: 60072
$427.10 ($42.71 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing EPS-400 is a dual wall tubing provides the advantage of integral, adhesive lined construction. This flame retardant tubing with a 4:1 shrink ratio offers insulation for 600V rated applications. The semi rigid polyolefin construction has an internal layer of thermoplastic adhesive which offers moisture seal protection in automotive and marine applications.

Features

  • Made of semi-rigid polyolefin
  • Offers protection for sealing voids in multiple wire bundles for automotive and marine applications
  • Dual-wall construction provides abrasion resistance and moisture-seal protection
  • Flame-retardant tubing is rated for 600V applications
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)
  • Offers the advantage of integral, adhesive-lined construction
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Overall Length (Imperial)6.0
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Inner Diameter Before Shrink (Metric) UOMmm
Heat Shrink TypeAdhesive-Lined Polyolefin Heat Shrink Tubing
Inner Diameter After Shrink (Imperial) UOMin
UL File NumberE-157227
Product ColorBlack
Inner Diameter After Shrink (Metric) UOMmm
Non-CorrosiveYes
Overall Length (Imperial) UOMin
Inner Diameter After Shrink (Imperial)0.8
MaterialPolyolefin
Shrink Ratio4:1
Flame RetardantYes
Maximum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Celsius) UomDegree
Maximum Operating Temperature (Fahrenheit)230.0
Inner Diameter Before Shrink (Imperial)0.35
Inner Diameter Before Shrink (Imperial) UOMin
Units per Case10.0
Minimum Expanded Tubing I. D. UOMin
Inner Diameter After Shrink (Metric)2.03
Operating Temperature (Celsius)-55 °C to 110 °C
Tubing TypeDual Wall (Adhesive Lined)
Minimum Expanded Tubing I. D.0.35
Maximum Operating Temperature (Celsius)110.0
Operating Temperature (Fahrenheit)-67 °F to 230 °F
Inner Diameter Before Shrink (Metric)8.89
