3M™ Transparent Conductor Film Assembly VT2022L 130mm x 200mm, 200EA/Case - 7100285427

Sold As: 1000-Pack
SKU: 7100285427
MPN: 7100285427
For an accurate lead time please contact us
UPC: 00638060909881
3M ID: XA006533047
$41,380.21 ($41.38 / Count)
Hurry up! Current stock:

Product Description

3M™ Transparent Conductor Film Assembly is a thin, transparent conductive film that has a custom copper grid pattern as the conductive layer. It can be laminated to a rigid transparent polycarbonate support to help enable wireless sub-6GHz antennas for indoor and outdoor settings. An innovative conductive transparent film, it uses a proprietary copper grid conductive layer to enable inconspicuous, high-power antenna designs with low surface electrical resistance.

Features

  • Implemented in low-profile antennas achieving VSWR, PIM and gain requirements that are typical for non-transparent antennas
  • Grid performance similar to solid copper
  • High power capability (up to 50W)
  • High efficiency (<0.05 ohms per square sheet resistance)
  • High transparency (>80% open area)
  • Proprietary copper grid conductive layer

Specifications

Overall Length (Metric) UOMmm
Overall Width (Metric) UOMmm
Overall Length (Imperial)5.118
ApplicationCPE/Repeater Antennas; DAS; Fleet Management; Infrared Sensors; Inventory Management; Neutral Host; Public Safety; Small Cell
Overall Width (Metric)200.0
Product ColorTransparent
Overall Width (Imperial)7.874
Overall Width (Imperial) UOMin
Overall Length (Imperial) UOMin
Country of OriginSouth Korea
Application TypeIn-building Wireless; IoT; Outdoor Wireless
Overall Length (Metric)130.0
