3M Products & Supplies

3M™ Ventureclad™ Enhanced Metal Jacketing 1577, CW-EMJ, 6 in X 50 yd, 4 Rolls/Case - 7100310802

Sold As: 144-Pack
SKU: 7100310802
MPN: 7100310802
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005410
3M ID: 70011144238
$25,621.30 ($177.93 / Count)
Hurry up! Current stock:

Product Description

3M™ VentureClad™ Enhanced Metal Jacketing 1577CW-EMJ is an all-weather option for various jacketing applications. It offers high resistance to weathering, mold, UV and extreme environmental conditions. This multi-layered laminate tape is designed to provide zero permeability and act as a vapor barrier. The additional clear coat layer of protection makes it more resistant and durable. Zero-permeable jacketing for insulated HVAC ductwork and pipes to protect against moisture, mold, ultraviolet (UV), and extreme environmental conditions. Backed by a 10-year 3M warranty when applied per 3M installation guidelines. It comes in silver smooth.

Features

  • Available in a smooth finish with a wide range of widths and lengths
  • Designed to protect insulation materials, including fiberglass, polystyrene, mineral wool, elastomeric, phenolic foam, cellular glass, calcium silicate and conformable aerogel
  • Quick and simple install with no specialized tools.
  • Bonds and seals in cold, hot and humid conditions as low as -10°F (-23°C) with service range of -40°F (-40°C) to248°F (120°C)
  • Protects against intrusion by vapor and chemical atmospheres as well as water, fungi, corrosion, oil and grease
  • Highly resistant to punctures and tears.
Spec Sheet



Downloads

Specifications

Shelf Life730
IndustriesCommercial, Construction, Food and Beverage, General Industrial, Industrial, MRO, Manufacturing, Marine, Military, Military and Government
Overall Width (Metric) UOMmm
Backing MaterialMulti-layered Laminate
Overall Length (Imperial) UOMyd
Country of OriginUnited States
Overall Length (Imperial)50.0
Shelf Life UOMMonth
Overall Width (Metric)152.4
Adhesive TypeAcrylic
Primary LinerPolycoated Natural Kraft Paper
Overall Length (Metric) UOMm
Overall Width (Imperial)6.0
Overall Width (Imperial) UOMin
Overall Length (Metric)45.72
Product ColorSilver
Tensile Strength (Imperial)100.0
Back Side Adhesive Thickness (Metric)0.0
Total Tape Thickness without Liner (Imperial)7.0
Minimum Operating Temperature (Fahrenheit)-40.0
Minimum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Metric)0.13
Maximum Operating Temperature (Celsius)120.0
Tensile Strength (Metric)27.0
Backing (Carrier) Thickness (Imperial)5.0
Maximum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Celsius)-40.0
Tensile Strength (Metric) UOMN/25mm
ApplicationDuctwork; Exterior Seams & Joints; HVAC Maintenance; Insulation; Sealing HVAC & Duct Work
Back Side Adhesive Thickness (Imperial)0.0
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric)0.177
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)248.0
Specifications MetASTM E84 (0/5 Flame/Smoke Rating), UL 723
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Imperial) UOMmil
