3M Products & Supplies

3M™ VHB™ Tape 4941F, Gray, 1 in x 36 yd, 45 mil, Film Liner, Small Pack, 2 rolls per case - 7000123670

Sold As: 2-Pack
SKU: 7000123670
MPN: 7000123670
Lead Time: 10 working days.
UPC: 021200261954
3M ID: 70006196524
5 Digit UPC: 26195
$306.73 ($153.37 / Count)
Hurry up! Current stock:

Product Description

Dream, Design, Deliver with 3M™ VHB™ Tape 4941. It is a gray, 0.045 in (1.1 mm), multi-purpose acrylic adhesive with a conformable, foam core. It can replace rivets, welds and screws. The fast and easy to use permanent bonding method provides high strength and long-term durability. It offers design flexibility with its viscoelasticity and powerful ability to bond to a variety of surfaces.

Features

  • UL GREENGUARD and UL GREENGUARD Gold Certified, contributing to LEED Credit
  • Fast and easy-to-use permanent bonding method provides high strength and long-term durability
  • Gray, 0.045 in (1.1 mm), multi-purpose adhesive and conformable acrylic foam core offers a good balance of strength and conformability
  • Creates a permanent seal against water, moisture and more
  • Pressure sensitive adhesive bonds on contact to provide immediate handling strength
  • Virtually invisible fastening keeps surfaces smooth
  • Can replace mechanical fasteners (rivets, welds, screws) or liquid adhesives
  • Allows the use of thinner, lighter weight and dissimilar materials
  • Eliminate drilling, grinding, refinishing, screwing, welding and associated clean-up

Downloads

Specifications

Substrate 1Sealed Wood - High Surface Energy Plastic - Metal - Glass - Paint - Plasticized Vinyl
Overall Width (Metric)25.4 mm
Maximum Operating Temperature (Celsius)149 Degree Celsius
Indoor/OutdoorIndoor/Outdoor
Net Weight (Metric)1.09 kg
Overall Thickness (Imperial)45 mil
Backing (Carrier) MaterialAcrylic Foam
Backing (Carrier) Thickness (Imperial)5 mil
Carrier MaterialAcrylic Foam
Product Key4941F
Overall Length (Imperial)36 yd
Overall Width (Imperial)1 in
Primary LinerPolyethylene (PE) Film
Overall Length (Metric)32.92 m
Net Weight (Imperial)2.4 lb
Product ColorGray
Backing Thickness (Imperial)5 mil
Overall Height (Imperial)45 mil
Primary Liner Thickness (Imperial)5 mil
Application Temperature-Environment60 Degrees Fahrenheit
Core Size (Imperial)3 in
Set Time
Product FormRoll
Application Temperature-Environment (Metric)16 Degree Celsius
SubstrateGlass - Rough Surfaces - Plastics (Flexible Vinyl) - LSE Plastics - Paint - Metal - HSE Plastics and Glass - Medium-High Surface Energy, (42-50 Dynes/cm) - Medium Surface Energy, (38-39 Dynes/cm) - High Surface Energy, (400-1100 Dynes/cm)
Design ChallengesNoise Vibration & Harshness Control NVH - Impact & Shock Absorption
Foam ConformabilityConformable
Adhesive TypeAcrylic
Overall Height (Metric)1.14 mm
Assembly TypePanel to Frame / Stiffener to Panel - Mounting and Trim Attachment
Overall Thickness (Metric)1.1 mm
Maximum Operating Temperature (Fahrenheit)300 Degree Fahrenheit
Temperature Resistance - Initial300 Degree Fahrenheit
Product Number4941
ApplicationBonding Panels to Metal Frames - Panel to Frame/Stiffner to Panel Assembly - Mounting and Trim Attachment - Gasket Assembly
Foam TypeConformable
