3M™ Vinyl Insulated Butted Seam Ring Tongue Terminal 13-56S-P, standard-style ring tongue fits around the stud - 7100163667

Sold As: 1000-Pack
SKU: 7100163667
MPN: 7100163667
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007287131
3M ID: 80601384284
MPN: 13-56S-P
$205.21 ($0.21 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Standard-style ring tongue fits around the stud
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

Minimum Stud Diameter (Imperial) UOMin
Minimum Conductor Size (Metric)3.31 mm²
UL File NumberE23438
Country of OriginUnited States
Barrel Length (Imperial)0.25 Inch
Terminal StyleStandard
Maximum Conductor Size (Imperial)10 AWG
Maximum Conductor Size (Metric)5.26
Ring TypeStandard
Insulation MaterialVinyl
Terminal TypeRing
Barrel StyleBrazed
Maximum Operating Temperature (Celsius) UOMDegree
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Minimum Stud Diameter (Metric)7.95
Maximum Operating Temperature (Celsius)175.0
Connection TypeCrimp
Minimum Stud Diameter (Metric) UOMmm
Minimum Conductor Size (Imperial)12 AWG
