Universal magnetic cordless core drill up to 1-3/8 [35] in[mm]|AJMU 137 PMQW - 71700261090

SKU: 71700261090
MPN: 71700261090
Stock Item: Stock items typically ship within 2-3 business days
UPC: 4014586888835
$2,261.06
Hurry up! Current stock:

Product Description

Universal magnetic cordless core drill up to 1-3/8 [35] in[mm]|AJMU 137 PMQW|Small, long-stroke, 1-speed universal cordless magnetic base drill with forward / reverse rotation, MT2 tool mounting, permanent magnet and maximum functionality for mobile work on the construction site.

Features

  • Motion sensor.
  • Extremely wear-resistant tool concept with swivel-mounted motor cable protection hose for tough conditions in industry and skilled trades.
  • FEIN HighPower Li-ion battery. Continuously high current output with 75% higher amperage than Li-ion batteries for high cutting speed.
  • Small and lightweight tool for persistently high long-term work progress thanks to brushless FEIN PowerDrive motor with tacho electronics and FEIN HighPower battery with high-current-capable cells.
  • Simple and error-proof control concept in the operator's field of view.
  • Convenient magnetic holding force display.
  • Flexibility in all mobile drilling operations, such as mag base drilling, spiral drilling, tapping, sinking and reaming.

Specifications

Max. countersinking dia. (in)1-1/4
Max. countersinking dia. (mm)31
Weight without battery (kg)12.10
HSS cutter max. dia. (in)1-3/8
Cutter holder3/4 in straight shank
Tapping9/16 in [M 14]
Twist drill max. dia. (in)3/4
HSS cutter max. dia. (mm)35
Tool mountMT 2
Total stroke range (in)10-1/4
Stroke (in)5-5/16
Magnetic base dimensions7-11/16 [195] x 2-3/4 [70] in[mm]
Weight without battery (lbs)26.68
Weight incl. battery (kg)12.80
Battery interface18 V
Battery compatibilityLi-ion / HighPower Li-ions**
Carbide cutter max. dia. (mm)35
Cutter max. drilling depth2 [50] (3 [75] )* in[mm]
Battery capacity5.2 Ah
Weight incl. battery (lbs)28.22
Reaming max. dia. (in)3/4
Twist drill max. dia. (mm)18
Cutter changetool-free
Carbide cutter max. dia. (in)1-3/8
Magnetic holding force (lbs)2023
Total stroke range (mm)260
Reaming max. dia. (mm)18
Motorbrushless
Stroke (mm)135
Full load speed130 - 520 rpm
Magnetic holding force (N)9,000
Battery voltage18 V
